Features
Quick accurate mitre adjustment and lock
Meet latest IEC table requirements and improve portability and handling
Roller bearing highly accurate system with minimum flex
It includes integrated short stop for repetitive cuts
Compatible with DeWALT DWS5026 guide rail clamps
Designed and machined for accuracy at low weight
The large dual sliding fence gives maximum support in large material cuts at any angle or combination of angles
Linear horizontal rails utilize bronze guides to provides maximum precision when cutting materials up to 305 mm wide
Quick release bevel setting provides accurate and simple setting of bevel angles up to 48 degree left ang right
Airlock compatible dust extraction improves cut lines visibility and provides cleaner and safer job sites
Wireless tool control allows automatic wireless connection to DCV586 extractor
Cam action mitre lock function allowing the user to quickly adjust between 0-50 degree left and 0-60 degree right
Compact and lightweight design characteristics deliver a saw with application focused capacities which is easy to transport around the job site
XPS shadow line cut indicator provides fast accurate alignment of the blade while illuminating the work piece for increased productivity
Innovative grooving stop allows the adjustment of the cutting depth for grooving and rebating applications
Specification
Battery Voltage: 54 volt
Recommended Battery Type: Lithium-Ion
Blade Diameter: 250 mm
Bevel Capacity: 49 degree
Bore Size: 16 mm
No-Load Speed: 4300 rpm
Maximum Depth of Cut: 150 mm
Maximum Cutting Capacity (45/45 degree): 210 × 50 mm
Maximum Cutting Capacity (45/90 degree): 210 × 77 mm
Maximum Cutting Capacity (90/45 degree): 305 × 50 mm
Maximum Cutting Capacity (90/90 degree): 305 × 77 mm
Mitre Capacity (Right/Left): 60/50 degree
Sound Power Level: 112 dB(A)
Sound PowerUncertainty K: 3 dB(A)
Sound Pressure Level: 100 dB(A)
Sound Pressure Uncertainty K: 3 dB(A)
Length: 770 mm
Height: 460 mm
Depth: 480 mm
Weight: 20.5 kg
