10.0 x 100/M12 Multi-Fix Bolt CSK Head 50 PCS

10.0 x 100/M12 Multi-Fix Bolt CSK Head 50 PCS

£44.57
(Inc. 20% VAT)
In stock, immediate dispatch
–
+
TIMCO micro plating technology gives a higher resistance to corrosion and enhances speed of installation
High-Low parallel threads for ease of insertion and high pull-out values
Removable & adjustable non-expansion through fixing
Unique concave thread configuration
Countersunk head gives a discreet finish into pre-counterunk holes
All steel, non-flammable fixing conforming to BS 7671 standard's 18th edition, which requires wiring systems to be supported by materials which are unlikely to prematurely collapse in the event of a fire.
Specification
SKU Code
MF10100C
Bar Code
5055893338421
Brand
Timco
Pack Type
Box
Pack Qty
50
Recess Type
TX Drive
Pallet Qty (pcs)
9,000
Finish
Exterior (Silver Organic)
Corrosion Rating (1-5)
3 - Urban &
Salt Spray Resistance (Hrs) Tested to BS EN 9227
400
MOQ
1
MOQ Increment
1
Driver Bit Size
TX50
Head Type
Countersunk
Point Type
Chamfered
Thread Type
High-Low Parallel
Packs per Carton
6
Packs per Pallet
180
Pack Dimensions L x W x H (mm)
162 x 140 x 84
Pack Weight (kg)
3.561
Approval
BS 7671:2018
Substrates
Wood, Concrete, Brick, Block, Stone
Included Items
TX50 V5 Impact Bit (Qty 1)
Drill Hole Ĝ (mm)
10.0
Fixture Hole Size Ĝ (mm)
12.0
MFT (mm)
50
Size Ĝ x L (mm)
10.0 x 100
Timco

Timco
Information

This stress free, non-expansion through fixing is the new solution for heavy duty anchoring into concrete, brick, stone, wood and concrete block replacing the need for traditional anchors such as throughbolts, shield, sleeve and drop-in anchors. Countersunk head for a flush finish.
